SRP200F
Battery Strap PTC, PolySwitch SRP, 30 VDC, 2 A, 4.4 A, 4 s, 100 A
Brug for flere?
| Antal | |
|---|---|
| 1+ | kr 5,510 |
| 50+ | kr 3,950 |
| 100+ | kr 3,780 |
| 250+ | kr 3,610 |
| 500+ | kr 3,330 |
| 1000+ | kr 3,080 |
Produktoplysninger
Produktoversigt
The SRP200F is a 2A PolySwitch Resettable Device with quarter-hard nickel leads and polyester tape. Raychem Circuit Protection, pioneer of polymeric PTC resettable device has developed several material platforms specifically tailored to help protect battery applications. Each of these material platforms offers different performance characteristics, allowing the engineer greater design flexibility. This SRP battery protector is compatible with high-volume electronics assembly and assists in meeting regulatory requirements. This resettable device increases battery operating time.
- Fast time-to-trip
- Low resistance devices increase battery operating time
Applikationer
Power Management, Portable Devices, Communications & Networking, Consumer Electronics
Advarsler
Intended for protection against occasional over-current or over-temperature fault conditions and should not be used when repeated fault conditions or prolonged trip events are anticipated.
Tekniske specifikationer
PolySwitch SRP
30VDC
4.4A
100A
85°C
Strap
2A
4s
-40°C
-
Tekniske dokumenter (2)
Alternativer til SRP200F
1 produkt fundet
Tilknyttede produkter
1 produkt fundet
Lovgivning og miljø
Det land, hvor den sidste væsentlige fremstillingsproces fandt stedOprindelsesland:China
Det land, hvor den sidste væsentlige fremstillingsproces fandt sted
RoHS
RoHS
Certifikater om produktoverholdelse
