Memory & SIM Card Connectors

Farnell supplies reliable memory and SIM card connectors for mobile, computing and embedded devices. These connectors ensure secure electrical contact, compact design and easy insertion/removal of memory or SIM cards.

Memory and SIM card connectors provide interface connections for flash memory, SD, microSD and SIM cards, enabling data access, storage and identification functionalities across digital systems.

Applications

Smartphones and tablets
Embedded computing devices
IoT and telecommunication equipment
Industrial communication modules

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price (ex VAT)	Pitch Spacing	Resistance	Memory / Card Type	Connector Type	Insert & Eject Mechanism	Power Rating	No. of Contacts	Resistance Tolerance	Contact Material	Resistor Case / Package	Contact Plating	No. of Rows	Product Range	Voltage Rating	Contact Termination Type	Resistor Technology	Temperature Coefficient	Resistor Type	Product Length	Product Width	Operating Temperature Min	Operating Temperature Max

2201778-1	2345280 Data Sheet RoHS	TE CONNECTIVITY Memory Card Connector MicroSD Push-Push Copper Gold Plated Contacts	Each (Supplied on Cut Tape) Cut Tape	1+kr 22.460 25+kr 14.600 75+kr 14.300 200+kr 14.000	-	-	MicroSD	Micro SD	Push-Push	-	-	-	Copper	-	Gold Plated Contacts	-	-	-	-	-	-	-	-	-	-	-
DM3BT-DSF-PEJS	1764375 Data Sheet RoHS	HIROSE / HRS Memory Card Connector MicroSD Push-Push 8 Contacts Copper Alloy Gold Plated Contacts DM3	Each (Supplied on Cut Tape) Cut Tape	1+kr 19.060 10+kr 14.350 100+kr 12.180 250+kr 11.440	-	-	MicroSD	Memory Socket	Push-Push	-	8Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	DM3	-	-	-	-	-	-	-	-	-
47309-2651	1568092 Data Sheet RoHS	MOLEX Memory Card Connector MicroSD Push-Pull 8 Contacts Copper Alloy Gold Plated Contacts	Each (Supplied on Cut Tape) Cut Tape	1+kr 14.570 12+kr 11.210 37+kr 9.720 100+kr 9.190	-	-	MicroSD	Micro SD	Push-Pull	-	8Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	47309 Series	-	-	-	-	-	-	-	-	-
SDAMB-01215BT00	9186140 Data Sheet RoHS	MULTICOMP PRO Memory Card Connector SD Push-Push 9 Contacts Copper Alloy Gold Plated Contacts SDAMB	Each	1+kr 20.110 10+kr 16.070 25+kr 13.750 50+kr 12.560 100+kr 12.030	-	-	SD	SD Card	Push-Push	-	9Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	SDAMB	-	-	-	-	-	-	-	-	-
693063020911	2081361 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Memory Card Connector SD Push-Pull 9 Contacts Copper Gold Plated Contacts WR-CRD	Each (Supplied on Cut Tape) Cut Tape	1+kr 25.640 10+kr 22.270 100+kr 17.490 250+kr 15.770	-	-	SD	Memory Socket	Push-Pull	-	9Contacts	-	Copper	-	Gold Plated Contacts	-	WR-CRD	-	-	-	-	-	-	-	-	-
47388-2001	2060729 Data Sheet RoHS	MOLEX Memory Card Connector Mini SIM Hinged 6 Contacts Copper Alloy Gold Plated Contacts	Each (Supplied on Cut Tape) Cut Tape	1+kr 13.230 20+kr 12.860 60+kr 12.480 160+kr 12.110	-	-	Mini SIM	Mini SIM	Hinged	-	6Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	47388 Series	-	-	-	-	-	-	-	-	-
78727-0001	2213307 Data Sheet RoHS	MOLEX Memory Card Connector Micro SIM Push-Pull 6 Contacts Copper Alloy Gold Plated Contacts	Each (Supplied on Cut Tape) Cut Tape	1+kr 10.160 30+kr 6.880 90+kr 6.730 240+kr 6.560	-	-	Micro SIM	Micro SIM	Push-Pull	-	6Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	78727 Series	-	-	-	-	-	-	-	-	-
693072010801	2081364 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Memory Card Connector MicroSD Hinged 8 Contacts Copper Gold Plated Contacts WR-CRD	Each (Supplied on Cut Tape) Cut Tape	1+kr 25.310 10+kr 22.010 100+kr 18.490 250+kr 18.120	-	-	MicroSD	Micro SD	Hinged	-	8Contacts	-	Copper	-	Gold Plated Contacts	-	WR-CRD	-	-	-	-	-	-	-	-	-
693071010811	2081363 Data Sheet RoHS	WURTH ELEKTRONIK Memory Card Connector MicroSD Push-Push 8 Contacts Copper Gold Plated Contacts WR-CRD	Each (Supplied on Cut Tape) Cut Tape	1+kr 23.470 10+kr 20.250 100+kr 17.120 250+kr 16.740	-	-	MicroSD	-	Push-Push	-	8Contacts	-	Copper	-	Gold Plated Contacts	-	WR-CRD	-	-	-	-	-	-	-	-	-
7431E0225S01LF	1098027 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Memory Card Connector Smart Card Push-Pull 8 Contacts Copper Alloy Gold Plated Contacts	Each	1+kr 39.240 10+kr 31.990 100+kr 27.650 250+kr 26.160	-	-	Smart Card	Smart Card	Push-Pull	-	8Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	FCI E	-	-	-	-	-	-	-	-	-
5145299-1	1284401 Data Sheet RoHS Date/Lot Code	AMP - TE CONNECTIVITY Memory Card Connector SIM / SAM Hinged 6 Contacts Phosphor Bronze Gold Plated Contacts	Each (Supplied on Cut Tape) Cut Tape	1+kr 37.000 12+kr 28.250 37+kr 26.460 100+kr 23.990	-	-	SIM / SAM	Memory Socket	Hinged	-	6Contacts	-	Phosphor Bronze	-	Gold Plated Contacts	-	-	-	-	-	-	-	-	-	-	-
SIMMP-00601B201-G	2211807 Data Sheet RoHS	MULTICOMP PRO Memory Card Connector Micro SIM 6 Contacts Gold Plated Contacts	Each	5+kr 6.530 10+kr 5.280 25+kr 4.140 50+kr 3.740 100+kr 3.620	-	-	Micro SIM	SIM Socket	-	-	6Contacts	-	-	-	Gold Plated Contacts	-	-	-	-	-	-	-	-	-	-	-
1565917-4	2112525 Data Sheet RoHS Date/Lot Code	AMP - TE CONNECTIVITY Memory Card Connector SODIMM Cam-In Locking 200 Contacts Copper Alloy Gold Plated Contacts	Each (Supplied on Cut Tape) Cut Tape	1+kr 65.440 3+kr 60.420 11+kr 55.400 30+kr 53.680	-	-	SODIMM	SODIMM Socket	Cam-In Locking	-	200Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	1565917	-	-	-	-	-	-	-	-	-
460DE08C3	1686452 Data Sheet RoHS	MULTICOMP Memory Card Connector MicroSD Hinged 8 Contacts Phosphor Bronze Gold Plated Contacts 460DE	Each (Supplied on Cut Tape) Cut Tape	1+kr 10.200 20+kr 8.040 60+kr 6.930 160+kr 6.610	-	-	MicroSD	Micro SD	Hinged	-	8Contacts	-	Phosphor Bronze	-	Gold Plated Contacts	-	460DE	-	-	-	-	-	-	-	-	-
502570-0893	2060731 Data Sheet RoHS	MOLEX Memory Card Connector MicroSD Push-Push 8 Contacts Copper Alloy Gold Plated Contacts	Each (Supplied on Cut Tape) Cut Tape	1+kr 30.420 32+kr 20.700 97+kr 19.580 260+kr 18.390	-	-	MicroSD	Micro SD	Push-Push	-	8Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	502570 Series	-	-	-	-	-	-	-	-	-
TFCMF-20801B0T0-UTE	1829768 Data Sheet RoHS	MULTICOMP PRO Memory Card Connector MicroSD Push-Push 8 Contacts Phosphor Bronze Gold Plated Contacts	Each	1+kr 9.870 10+kr 8.370 25+kr 7.180 50+kr 7.160 100+kr 7.140	-	-	MicroSD	Micro SD	Push-Push	-	8Contacts	-	Phosphor Bronze	-	Gold Plated Contacts	-	TFCMF	-	-	-	-	-	-	-	-	-
N7E50-7516PK-20	1034424 Data Sheet RoHS	3M Memory Card Connector PC Card CompactFlash Card Type I Push-Pull 50 Contacts Copper Alloy	Each	1+kr 90.810 10+kr 73.100 100+kr 62.040 250+kr 57.400	0.635mm	-	CompactFlash Card Type I	-	Push-Pull	-	50Contacts	-	Copper Alloy	-	Gold Plated Contacts	2Rows	7E50 Series	-	Solder	-	-	-	-	-	-	-
SDCMF-10715W1T0	9186190 Data Sheet RoHS	MULTICOMP PRO Memory Card Connector MultiMediaCard (MMC) Push-Push 7 Contacts Phosphor Bronze	Each	1+kr 21.380 10+kr 17.120 25+kr 14.650 50+kr 13.380 100+kr 12.780	-	-	MultiMediaCard (MMC)	MMC, SD	Push-Push	-	7Contacts	-	Phosphor Bronze	-	Gold Plated Contacts	-	-	-	-	-	-	-	-	-	-	-
SDBMF-00915B0T2	9186174 Data Sheet RoHS	MULTICOMP PRO Memory Card Connector SD Push-Push 9 Contacts Phosphor Bronze Gold Plated Contacts SDBMF	Each	1+kr 31.320 10+kr 25.110 25+kr 21.450	-	-	SD	-	Push-Push	-	9Contacts	-	Phosphor Bronze	-	Gold Plated Contacts	-	SDBMF	-	-	-	-	-	-	-	-	-
DM3D-SF	1764377 Data Sheet RoHS	HIROSE / HRS Memory Card Connector MicroSD Push-Pull 8 Contacts Copper Alloy Gold Plated Contacts DM3	Each (Supplied on Cut Tape) Cut Tape	1+kr 13.900 10+kr 10.840 100+kr 8.890 500+kr 8.000	-	-	MicroSD	Memory Socket	Push-Pull	-	8Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	DM3	-	-	-	-	-	-	-	-	-
693061010911	2081359 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Memory Card Connector SD Push-Push 9 Contacts Copper Gold Plated Contacts WR-CRD	Each	1+kr 38.260 10+kr 33.620 100+kr 28.300 250+kr 24.260	-	-	SD	Memory Socket	Push-Push	-	9Contacts	-	Copper	-	Gold Plated Contacts	-	WR-CRD	-	-	-	-	-	-	-	-	-
503398-1892	2358234 Data Sheet RoHS	MOLEX Memory Card Connector MicroSD Push-Push 8 Contacts Copper Alloy Gold Plated Contacts	Each (Supplied on Cut Tape) Cut Tape	1+kr 19.810 60+kr 13.300 180+kr 12.710 480+kr 11.880	-	-	MicroSD	Micro SD	Push-Push	-	8Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	503398 Series	-	-	-	-	-	-	-	-	-
DM3CS-SF	1764376 Data Sheet RoHS	HIROSE / HRS Memory Card Connector MicroSD Hinged 8 Contacts Copper Alloy Gold Plated Contacts DM3	Each (Supplied on Cut Tape) Cut Tape	1+kr 11.960 32+kr 8.000 97+kr 7.550 260+kr 7.150	-	-	MicroSD	Memory Socket	Hinged	-	8Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	DM3	-	-	-	-	-	-	-	-	-
1612618-4	2396418 Data Sheet RoHS Date/Lot Code	AMP - TE CONNECTIVITY Memory Card Connector SODIMM Cam-In Locking 200 Contacts Copper Alloy Gold Plated Contacts	Each	1+kr 52.170 10+kr 33.190 100+kr 30.640 250+kr 30.050	-	-	SODIMM	SODIMM Socket	Cam-In Locking	-	200Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	-	-	-	-	-	-	-	-	-	-
DM3AT-SF-PEJM5(40)	1764374 Data Sheet RoHS	HIROSE / HRS Memory Card Connector MicroSD Push-Push 8 Contacts Copper Alloy Gold Plated Contacts DM3	Each (Supplied on Cut Tape) Cut Tape	1+kr 23.840 10+kr 17.940 100+kr 15.770 250+kr 15.320	-	-	MicroSD	Micro SD	Push-Push	-	8Contacts	-	Copper Alloy	-	Gold Plated Contacts	-	DM3	-	-	-	-	-	-	-	-	-
