Thermoelectric Modules & Assemblies :
424 produkter blev fundetFind et stort udvalg af Thermoelectric Modules & Assemblies hos Farnell Danmark. Vi har et stort udvalg af Thermoelectric Modules & Assemblies på lager, inklusive nye og mest populære produkter fra verdens førende producenter herunder: Same Sky, Multicomp Pro, European Thermodynamics, Marlow Industries & Wakefield Thermal
Alle filtre
Vis alle
Producent
(35)
(119)
(10)
(5)
(1)
(5)
(237)
(4)
(1)
Transducer Function
(112)
Module Type
(30)
(2)
No. of Stages
(142)
(11)
(1)
Power Rating
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
Cooling Power Pc
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
Current Max @ Diff Temperature Max
(1)
(4)
(1)
(1)
(1)
(1)
(2)
(4)
Voltage Max @ Diff Temperature Max
(1)
(1)
(1)
(2)
(2)
(1)
(1)
(2)
Length
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(2)
Width
(1)
(1)
(2)
(1)
(1)
(1)
(1)
(3)
Depth
(1)
(1)
(2)
(1)
(1)
(2)
(1)
(1)
Emballage
(424)
| Sammenlign | Producentens varenummer | Ordrekode | Producent / Beskrivelse | Tilgængelighed | Pris for | Pris (ekskl. Moms) | Antal | Transducer Function | Module Type | No. of Stages | Power Rating | Cooling Power Pc | Current Max @ Diff Temperature Max | Voltage Max @ Diff Temperature Max | Length | Width | Depth | Temperature Difference Max | Product Range | Internal Resistance | Lead Wires |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Each | 1+kr 268,340 5+kr 225,910 10+kr 195,170 20+kr 191,220 | Thermoelectric Cooler | - | 1 Stage | 35.2W | 35.2W | 3.9A | 15.7VDC | 30mm | 30mm | 3.65mm | 70°C | MCPE | 3.5ohm | 100mm, UL-Style 1569, Unstripped | ||||||
Each | 1+kr 441,030 5+kr 371,360 10+kr 320,740 20+kr 314,340 | Thermoelectric Cooler | - | 1 Stage | 55W | 55W | 6A | 15.7VDC | 30mm | 30mm | 3.1mm | 69°C | MCHPE | 2.3ohm | 100mm, UL-Style 1569, Unstripped | ||||||
MULTICOMP PRO | Each | 1+kr 403,320 3+kr 343,960 10+kr 334,430 25+kr 319,900 | Thermoelectric Cooler | - | 2 Stage | 51.6W | 51.6W | 8.5A | 16.1VDC | 40mm | 40mm | 7.05mm | 85°C | MCPK | 1.65ohm | UL-Style 1569, Unstripped | |||||
Each | 1+kr 240,390 3+kr 206,910 10+kr 182,560 25+kr 178,970 100+kr 170,050 | Thermoelectric Cooler | - | 1 Stage | 77.1W | 77.1W | 8.5A | 15.7VDC | 40mm | 40mm | 3.45mm | 70°C | MCPE | - | UL-Style 1569, Unstripped | ||||||
MULTICOMP PRO | Each | 1+kr 1.397,000 | Thermoelectric Cooler | - | 1 Stage | 340W | 340W | 15.4A | 35.8VDC | 50mm | 50mm | 3.9mm | 68°C | MCHPE | 1.9ohm | 100mm, UL-Style 1569, Unstripped | |||||
MULTICOMP PRO | Each | 1+kr 266,250 5+kr 224,200 10+kr 193,600 20+kr 189,730 | Thermoelectric Cooler | - | 1 Stage | 43.1W | 43.1W | 8.5A | 8.8VDC | 30mm | 30mm | 3.45mm | 70°C | MCPE | 0.85ohm | UL-Style 1569, Unstripped | |||||
MULTICOMP PRO | Each | 1+kr 405,930 3+kr 346,200 10+kr 336,590 25+kr 321,990 | Thermoelectric Cooler | - | 1 Stage | 79W | 79W | 8.5A | 15.7VDC | 40mm | 40mm | 3.8mm | 70°C | MCPF | 1.59ohm | UL-Style 1569, Unstripped | |||||
Each | 1+kr 280,470 5+kr 236,180 10+kr 203,950 20+kr 199,860 | Thermoelectric Cooler | - | 1 Stage | 55.6W | 55.6W | 6A | 15.7VDC | 40mm | 40mm | 3.95mm | 70°C | MCPE | 2.2ohm | UL-Style 1569, Unstripped | ||||||
Each | 1+kr 288,510 5+kr 242,960 10+kr 209,760 20+kr 205,510 | Thermoelectric Cooler | - | 1 Stage | 29.7W | 29.7W | 6A | 8.8VDC | 20mm | 20mm | 3.1mm | 70°C | MCPE | 1.05ohm | UL-Style 1569, Unstripped | ||||||
MULTICOMP PRO | Each | 1+kr 309,760 3+kr 266,610 10+kr 235,220 25+kr 230,510 | Thermoelectric Cooler | - | 1 Stage | 118W | 118W | 8.5A | 24.1VDC | 40mm | 40mm | 3.5mm | 68°C | MCTE | 2.35ohm | UL-Style 1569, Unstripped | |||||
MULTICOMP PRO | Each | 1+kr 271,860 3+kr 234,030 10+kr 206,460 25+kr 202,340 100+kr 192,300 | Thermoelectric Cooler | - | 1 Stage | 130W | 130W | 15A | 15.4VDC | 50mm | 50mm | 3.5mm | 68°C | MCTE | 0.8ohm | 150mm, UL-Style 1569, Unstripped | |||||
MULTICOMP PRO | Each | 1+kr 299,870 3+kr 258,150 10+kr 227,730 25+kr 223,160 | Thermoelectric Cooler | - | 1 Stage | 38.1W | 38.1W | 3.9A | 15.7VDC | 30mm | 30mm | 3.6mm | 75°C | MCPE | 3.6ohm | 100mm, UL-Style 1569, Unstripped | |||||
Each | 1+kr 415,870 5+kr 350,220 10+kr 302,430 20+kr 296,400 | - | - | 1 Stage | - | 237W | 14A | 24.1VDC | 50mm | 50mm | 3.5mm | 68°C | MCTE | 1.4ohm | 150mm, UL-Style 1569, Unstripped | ||||||
EUROPEAN THERMODYNAMICS | Each | 1+kr 232,000 5+kr 198,890 10+kr 183,160 20+kr 158,290 50+kr 155,140 | Thermoelectric Cooler | - | 1 Stage | 8W | 8W | 3.8A | 3.78VDC | 15mm | 15mm | 3.3mm | 67°C | APH Series | - | 150mm, UL-Style 1569, Unstripped | |||||
EUROPEAN THERMODYNAMICS | Each | 1+kr 475,390 5+kr 400,330 10+kr 345,720 20+kr 338,800 | Thermoelectric Cooler | - | 1 Stage | 165W | 165W | 12A | 24.1VDC | 40mm | 40mm | 3.5mm | 67°C | APH Series | - | 100mm, UL-Style 1569, Unstripped | |||||
Each | 1+kr 112,990 3+kr 103,380 10+kr 98,390 25+kr 90,050 100+kr 87,520 | Thermoelectric Cooler | - | 1 Stage | 51W | 51W | 6A | 15.4VDC | 40mm | 40mm | 3.8mm | 65°C | MPADV | - | 200mm, 20 AWG, PTFE Insulated | ||||||
Each | 1+kr 425,500 3+kr 366,170 10+kr 323,100 25+kr 316,650 | - | - | 1 Stage | - | 20.9W | 2.2A | 15.7VDC | 25mm | 25mm | 3.8mm | 74°C | MPET | - | 100mm, UL-Style 1569, Unstripped | ||||||
MULTICOMP PRO | Each | 1+kr 472,670 3+kr 403,030 10+kr 391,930 25+kr 374,870 | Thermoelectric Cooler | - | 1 Stage | 71.8W | 71.8W | 3.9A | 29.8VDC | 40mm | 40mm | 3.6mm | 74°C | MCPE | 6.8ohm | 100mm, UL-Style 1569, Unstripped | |||||
Each | 1+kr 288,510 5+kr 242,960 10+kr 209,760 20+kr 205,510 | Thermoelectric Cooler | - | 1 Stage | 30W | 30W | 6A | 8.8VDC | 20mm | 20mm | 3.1mm | 69°C | MCHPE | 1.21ohm | 100mm, UL-Style 1569, Unstripped | ||||||
MULTICOMP PRO | Each | 1+kr 404,960 3+kr 345,380 10+kr 335,840 25+kr 321,240 | Thermoelectric Cooler | - | 1 Stage | 57.9W | 57.9W | 6A | 15.7VDC | 40mm | 40mm | 3.9mm | 72°C | MCPF | 2.2ohm | UL-Style 1569, Unstripped | |||||
MULTICOMP PRO | Each | 1+kr 259,500 3+kr 223,310 10+kr 197,090 25+kr 193,120 100+kr 183,540 | Thermoelectric Cooler | - | 1 Stage | 7.5W | 7.5W | 3.2A | 3.8VDC | 15mm | 15mm | 3.8mm | 74°C | MCPE | 1.03ohm | UL-Style 1569, Unstripped | |||||
MULTICOMP PRO | Each | 1+kr 119,100 3+kr 108,970 10+kr 103,750 25+kr 94,970 100+kr 92,210 | Thermoelectric Cooler | - | 1 Stage | 18.8W | 18.8W | 8.5A | 3.8VDC | 20mm | 20mm | 3.4mm | 70°C | MCPE | 0.35ohm | UL-Style 1569, Unstripped | |||||
MULTICOMP PRO | Each | 1+kr 288,510 5+kr 242,960 10+kr 209,760 20+kr 205,510 | Thermoelectric Cooler | - | 1 Stage | 31.1W | 31.1W | 6A | 8.8VDC | 30mm | 30mm | 3.95mm | 70°C | MCPE | 1.25ohm | UL-Style 1569, Unstripped | |||||
MULTICOMP PRO | Each | 1+kr 383,590 | Thermoelectric Cooler | - | 1 Stage | 19.6W | 19.6W | 2A | 15.7VDC | 30mm | 30mm | 4.8mm | 75°C | MCPE | 6.9ohm | UL-Style 1569, Unstripped | |||||
Each | 1+kr 501,270 3+kr 427,460 10+kr 415,610 | Thermoelectric Cooler | - | 1 Stage | 88W | 88W | 9A | 15.8VDC | 30mm | 30mm | 3.6mm | 68°C | MCHPE | 1.4ohm | 100mm, UL-Style 1569, Unstripped | ||||||
