Isolated Surface Mount DC / DC Converters

Find et stort udvalg af Isolated Surface Mount DC / DC Converters hos Farnell Danmark. Vi har et stort udvalg af Isolated Surface Mount DC / DC Converters på lager, inklusive nye og mest populære produkter fra verdens førende producenter herunder: Recom Power, Xp Power, Traco Power, Cui & Murata Power Solutions

Producent

Power Supply Applications

Input Voltage Min

DC / DC Converter Type

Input Voltage Max

Input Ratio

Output Power Max

DC / DC Converter IC Case

No. of Outputs

No. of Pins

Output Voltage - Output 1

Output Current

Output Current - Output 1

Output Voltage - Output 3

Output Voltage Nom

Output Voltage - Output 2

Output Current - Output 3

Output Voltage Min

Output Current - Output 2

Output Voltage Max

Switching Frequency

Output Regulation

Operating Temperature Max

Topology

Isolation Voltage

Input Voltage DC Nom

DC / DC Converter Output Type

DC / DC Converter Mounting

Width

Height

Depth

Input Voltage DC Min

Input Voltage DC Max

Product Range

Emballage

Ingen filtre anvendt

0 Filtre valgt

			Pris for		Antal

TES 1-0511	1635248 Data Sheet RoHS	TRACO POWER Isolated Surface Mount DC/DC Converter ITE 1:1 1 W 1 Output 5 V	Each	1+ kr 40,670 10+ kr 37,760 25+ kr 36,940 50+ kr 36,340 100+ kr 35,740	Min: 1 / Flere: 1	ITE	-	-	-	1:1	1W	-	1 Output	-	5V	-	200mA	-	-	-	-	-	-	-	-	Unregulated	-	-	1.5kV	5V	Fixed	Surface Mount Device	8mm	6.7mm	13.7mm	4.5V	5.5V	TES 1 Series
TDN 1-1215WISM	2813000 Data Sheet RoHS	TRACO POWER Isolated Surface Mount DC/DC Converter ITE 4:1 1 W 1 Output 24 V	Each	1+ kr 115,810	Min: 1 / Flere: 1	ITE	-	-	-	4:1	1W	-	1 Output	-	24V	-	45mA	-	-	-	-	-	-	-	-	Regulated	-	-	1.6kV	12V	Fixed	Surface Mount Device	9.1mm	10.2mm	13.2mm	4.5V	18V	TDN 1WISM Series
DCP020507U	3123105 RoHS Date/Lot Code	TEXAS INSTRUMENTS Isolated Surface Mount DC/DC Converter Industrial Module 2 W 1 Output 7 V	Each	1+ kr 100,100 5+ kr 100,020 10+ kr 99,950	Min: 1 / Flere: 1	Industrial	4.5V	Module	5.5V	-	2W	SOP	1 Output	28Pins	7V	286mA	285mA	-	7V	-	-	-	-	-	800kHz	Unregulated	85°C	-	1kV	5V	Fixed	-	7.6mm	2.65mm	18.1mm	4.5V	5.5V	DCP02 Series
TDN 3-4812WISM	2813043 Data Sheet RoHS	TRACO POWER Isolated Surface Mount DC/DC Converter ITE 4:1 3 W 1 Output 12 V	Each	1+ kr 189,460 10+ kr 165,810 25+ kr 162,530 50+ kr 159,170 100+ kr 155,890	Min: 1 / Flere: 1	ITE	-	-	-	4:1	3W	-	1 Output	-	12V	-	250mA	-	-	-	-	-	-	-	-	Regulated	-	-	1.6kV	48V	Fixed	Surface Mount Device	9.1mm	10.2mm	13.2mm	18V	75V	TDN 3WISM Series
TRS 2-1219	3795793 Data Sheet RoHS	TRACO POWER Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 2:1 2 W 1 Output 9 V	Each	1+ kr 84,770	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	2:1	2W	-	1 Output	-	9V	-	222mA	-	-	-	-	-	-	-	-	Regulated	-	-	1.6kV	12V	Fixed	-	11.3mm	7.6mm	11.9mm	9V	18V	TRS 2 Series
CCG1R5-48-15DR	4051218 Data Sheet RoHS Date/Lot Code	TDK-LAMBDA Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 4:1 1.5 W 2 Output 15 V	Each	1+ kr 91,260 5+ kr 89,620 10+ kr 87,900 20+ kr 84,550 50+ kr 81,110	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	4:1	1.5W	-	2 Output	-	15V	-	50mA	-	-	-15V	-	-	-50mA	-	-	Regulated	-	-	1.5kV	48V	Fixed	-	10.4mm	11.5mm	15.7mm	18V	76V	CCG1R5 Series
R3M-1205S/SMD	4155288 Data Sheet RoHS	RECOM POWER Isolated Surface Mount DC/DC Converter Surface Mount DIP 4:1 3 W 1 Output 5 V	Each	1+ kr 145,370	Min: 1 / Flere: 1	-	-	Surface Mount DIP	-	4:1	3W	-	1 Output	-	5V	-	600mA	-	-	-	-	-	-	-	-	Regulated	-	-	1.6kV	12V	Fixed	-	9.1mm	10.2mm	13.2mm	4.5V	18V	R3M Series
R1M-2412D/SMD	4155274 Data Sheet RoHS	RECOM POWER Isolated Surface Mount DC/DC Converter Surface Mount DIP 4:1 1 W 2 Output 12 V	Each	1+ kr 156,330 5+ kr 150,590	Min: 1 / Flere: 1	-	-	Surface Mount DIP	-	4:1	1W	-	2 Output	-	12V	-	45mA	-	-	-12V	-	-	-45mA	-	-	Regulated	-	-	1.6kV	24V	Fixed	-	9.1mm	10.2mm	13.2mm	9V	36V	R1M Series
LTM8057EY#PBF	4026700 Data Sheet RoHS Date/Lot Code	ANALOG DEVICES DC/DC POL Converter Adjustable Isolated Flyback 3.1 to 31 V in 2.5 to 12V/0.44A out BGA-38	Each	1+ kr 128,490 10+ kr 126,390 25+ kr 123,780	Min: 1 / Flere: 1	Industrial	3.1V	BGA-38, Micro Module	31V	-	-	BGA	1 Output	38Pins	-	440mA	-	-	-	-	-	2.5V	-	12V	-	Regulated	125°C	Isolated Flyback	2kV	-	Adjustable	-	9mm	4.92mm	11.25mm	3.1V	31V	LTM8057 Series
CCG1R5-24-12DR	4051202 Data Sheet RoHS Date/Lot Code	TDK-LAMBDA Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 4:1 1.56 W 2 Output 12 V	Each	1+ kr 91,260 5+ kr 89,620 10+ kr 87,900	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	4:1	1.56W	-	2 Output	-	12V	-	65mA	-	-	-12V	-	-	-65mA	-	-	Regulated	-	-	1.5kV	24V	Fixed	-	10.4mm	11.5mm	15.7mm	9V	36V	CCG1R5 Series
TRI 1-1211SM	4175964 Data Sheet RoHS	TRACO POWER Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 1 W 1 Output 5 V	Each	1+ kr 95,890 10+ kr 74,620 25+ kr 72,980	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	-	1W	-	1 Output	-	5V	-	200mA	-	-	-	-	-	-	-	-	Regulated	-	-	3kV	12V	Fixed	-	13.7mm	10.2mm	18.9mm	10.8V	13.2V	TRI 1SM Series
CCG1R5-12-15DR	4051192 Data Sheet RoHS Date/Lot Code	TDK-LAMBDA Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 4:1 1.5 W 2 Output 15 V	Each	1+ kr 87,900 5+ kr 86,110 10+ kr 84,400 20+ kr 82,610	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	4:1	1.5W	-	2 Output	-	15V	-	50mA	-	-	-15V	-	-	-50mA	-	-	Regulated	-	-	1.5kV	12V	Fixed	-	10.4mm	11.5mm	15.7mm	4.5V	18V	CCG1R5 Series
CCG1R5-48-05SR	4051209 Data Sheet RoHS Date/Lot Code	TDK-LAMBDA Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 4:1 1.5 W 1 Output 5 V	Each	1+ kr 91,260 5+ kr 89,620 10+ kr 87,900	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	4:1	1.5W	-	1 Output	-	5V	-	300mA	-	-	-	-	-	-	-	-	Regulated	-	-	1.5kV	48V	Fixed, Adjustable	-	10.4mm	11.5mm	15.7mm	18V	76V	CCG1R5 Series
RSH3-1215D/H2	4063585 Data Sheet RoHS	RECOM POWER Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 3 W 2 Output 15 V	Each	1+ kr 84,920 5+ kr 83,200 10+ kr 81,490 20+ kr 79,850	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	-	3W	-	2 Output	-	15V	-	100mA	-	-	-15V	-	-	-100mA	-	-	Regulated	-	-	2kV	12V	Fixed	-	17.2mm	8.7mm	18.9mm	9V	18V	RSH3 Series
LTM8067IY	4026703 Data Sheet Date/Lot Code	ANALOG DEVICES DC/DC POL Converter Adjustable Isolated Flyback 3 to 40 V in 2.5 to 24V/0.45A out BGA-38	Each	1+ kr 253,390 10+ kr 214,760 25+ kr 205,130 168+ kr 175,020 336+ kr 171,510	Min: 1 / Flere: 1	Industrial	3V	BGA-38, Micro Module	40V	-	-	BGA	1 Output	38Pins	-	450mA	-	-	-	-	-	2.5V	-	24V	-	Regulated	125°C	Isolated Flyback	2kV	-	Adjustable	-	9mm	4.92mm	11.25mm	2.8V	40V	LTM8067 Series
PQP3-D12-S3-M	3595206 Data Sheet RoHS	CUI Isolated Surface Mount DC/DC Converter ITE DIP 2:1 2.5 W 1 Output 3.3 V	Each	1+ kr 122,810 5+ kr 92,850 10+ kr 89,340 20+ kr 85,830	Min: 1 / Flere: 1	ITE	-	DIP	-	2:1	2.5W	-	1 Output	-	3.3V	-	758mA	-	-	-	-	-	-	-	-	-	-	-	1.5kV	12V	Fixed	-	14mm	9mm	14mm	9V	18V	PQP3-M Series
IAS0112D15	3890251 Data Sheet RoHS	XP POWER Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 1:1 1 W 2 Output 15 V	Each	1+ kr 20,890 5+ kr 20,450 10+ kr 20,070 50+ kr 19,630 100+ kr 19,250	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	1:1	1W	-	2 Output	-	15V	-	34mA	-	-	-15V	-	-	34mA	-	-	Unregulated	-	-	1.5kV	12V	Fixed	-	8.5mm	7.25mm	15.24mm	10.8V	13.2V	IAS Series
PESE2-S24-S15-M	3873695 Data Sheet RoHS	CUI Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 1:1 2 W 1 Output 15 V	Each	1+ kr 78,650 5+ kr 64,170 10+ kr 59,470 20+ kr 53,880 50+ kr 48,280	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	1:1	2W	-	1 Output	-	15V	-	133mA	-	-	-	-	-	-	-	-	Unregulated	-	-	3kV	24V	Fixed	-	11.4mm	7.25mm	13.2mm	21.6V	26.4V	PESE2-M Series
IAS0112D09	3890249 Data Sheet RoHS	XP POWER Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 1:1 1 W 2 Output 9 V	Each	1+ kr 24,550 5+ kr 23,880 10+ kr 23,280 50+ kr 22,610 100+ kr 22,160	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	1:1	1W	-	2 Output	-	9V	-	56mA	-	-	-9V	-	-	56mA	-	-	Unregulated	-	-	1.5kV	12V	Fixed	-	8.5mm	7.25mm	15.24mm	10.8V	13.2V	IAS Series
IES0124S12	3890266 Data Sheet RoHS	XP POWER Isolated Surface Mount DC/DC Converter ITE Surface Mount DIP 1:1 1 W 1 Output 12 V	Each	1+ kr 22,460 5+ kr 22,240 10+ kr 22,010 50+ kr 21,790 100+ kr 21,340	Min: 1 / Flere: 1	ITE	-	Surface Mount DIP	-	1:1	1W	-	1 Output	-	12V	-	84mA	-	-	-	-	-	-	-	-	Unregulated	-	-	1.5kV	24V	Fixed	-	8.5mm	7.25mm	13.2mm	21.6V	26.4V	IES01 Series
NTE0505MC	1021599 Data Sheet RoHS	MURATA POWER SOLUTIONS Isolated Surface Mount DC/DC Converter Miniature ITE 1:1 1 W 1 Output 5 V	Each	1+ kr 56,550 5+ kr 56,250 10+ kr 55,800 20+ kr 54,910 50+ kr 53,930	Min: 1 / Flere: 1	ITE	-	-	-	1:1	1W	-	1 Output	-	5V	-	200mA	-	-	-	-	-	-	-	-	Unregulated	-	-	1kV	5V	Fixed	Surface Mount Device	7.7mm	6.6mm	12.7mm	4.5V	5.5V	NTE Series
TES 2N-2411	1007061 Data Sheet RoHS	TRACO POWER Isolated Surface Mount DC/DC Converter ITE 2:1 2 W 1 Output 5 V	Each	1+ kr 173,980 10+ kr 153,060 25+ kr 149,780 50+ kr 147,310 100+ kr 144,920	Min: 1 / Flere: 1	ITE	-	-	-	2:1	2W	-	1 Output	-	5V	-	400mA	-	-	-	-	-	-	-	-	Regulated	-	-	1.5kV	24V	Fixed	Surface Mount Device	13.7mm	8.25mm	24mm	18V	36V	TES 2N Series
TES 1-2411	1635261 Data Sheet RoHS	TRACO POWER Isolated Surface Mount DC/DC Converter ITE 1:1 1 W 1 Output 5 V	Each	1+ kr 54,010 10+ kr 49,530 25+ kr 48,480 50+ kr 47,730 100+ kr 46,910	Min: 1 / Flere: 1	ITE	-	-	-	1:1	1W	-	1 Output	-	5V	-	200mA	-	-	-	-	-	-	-	-	Unregulated	-	-	1.5kV	24V	Fixed	Surface Mount Device	8mm	6.7mm	13.7mm	21.6V	26.4V	TES 1 Series
NTE0512MC	1021601 Data Sheet RoHS	MURATA POWER SOLUTIONS Isolated Surface Mount DC/DC Converter Miniature ITE 1:1 1 W 1 Output 12 V	Each	1+ kr 54,910 5+ kr 54,610 10+ kr 54,160 20+ kr 53,260 50+ kr 52,370	Min: 1 / Flere: 1	ITE	-	-	-	1:1	1W	-	1 Output	-	12V	-	83mA	-	-	-	-	-	-	-	-	Unregulated	-	-	1kV	5V	Fixed	Surface Mount Device	7.7mm	6.6mm	12.7mm	4.5V	5.5V	NTE Series
TSM 0505S	1205072 Data Sheet RoHS	TRACO POWER Isolated Surface Mount DC/DC Converter ITE 1:1 1 W 1 Output 5 V	Each	1+ kr 61,400 10+ kr 58,270 25+ kr 57,000 50+ kr 56,100 100+ kr 55,200	Min: 1 / Flere: 1	ITE	-	-	-	1:1	1W	-	1 Output	-	5V	-	200mA	-	-	-	-	-	-	-	-	Unregulated	-	-	1kV	5V	Fixed	Surface Mount Device	8mm	6.8mm	12.7mm	4.5V	5.5V	TSM Series
