MELF SMD Resistors | Farnell Danmark

Find et stort udvalg af MELF SMD Resistors hos Farnell Danmark. Vi har et stort udvalg af MELF SMD Resistors på lager, inklusive nye og mest populære produkter fra verdens førende producenter herunder: Neohm - Te Connectivity, Vishay, Multicomp Pro, Yageo & Tt Electronics / Welwyn

Producent

Resistance

Product Range

Voltage Rating

Resistor Technology

Power Rating

Resistance Tolerance

Temperature Coefficient

Resistor Case / Package

Operating Temperature Min

Operating Temperature Max

Qualification

Emballage

Ingen filtre anvendt

0 Filtre valgt

			Pris for		Antal

MMU01020C1002FB300	1215959 Data Sheet RoHS Date/Lot Code	VISHAY Surface Mount MELF Resistor 10 kohm MMU Series 100 V Metal Film 200 mW ± 1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 0,711 50+ kr 0,548 250+ kr 0,462 500+ kr 0,358 1500+ kr 0,304 Flere priser...	Min: 5 / Flere: 5	10kohm	MMU Series	100V	Metal Film	200mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	125°C	AEC-Q200
CMA02040X1000GB300	1713576 Data Sheet RoHS Date/Lot Code	VISHAY Surface Mount MELF Resistor 100 ohm CMA Series 200 V Carbon Film 400 mW ± 2%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 2,780 50+ kr 1,370 250+ kr 1,140 500+ kr 1,080 1500+ kr 0,985 Flere priser...	Min: 5 / Flere: 5	100ohm	CMA Series	200V	Carbon Film	400mW	± 2%	-250ppm/K	MiniMELF 0204	-55°C	155°C	AEC-Q200
MMU01020C6800FB300	1215926 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 680 ohm MMU Series 100 V Metal Film 200 mW ± 1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 0,711 50+ kr 0,548 250+ kr 0,512 500+ kr 0,419 1500+ kr 0,335 Flere priser...	Min: 5 / Flere: 5	680ohm	MMU Series	100V	Metal Film	200mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	125°C	AEC-Q200
WRM0204C-2K7FI	1505809 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 2.7 kohm WRM Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 1,510 50+ kr 0,640 250+ kr 0,549 500+ kr 0,459 1500+ kr 0,308 Flere priser...	Min: 5 / Flere: 5	2.7kohm	WRM Series	200V	Metal Film	250mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	125°C	-
WRM0204C-1K8FI	1505807 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 1.8 kohm WRM Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 1,510 50+ kr 0,640 250+ kr 0,549 500+ kr 0,459 1500+ kr 0,308 Flere priser...	Min: 5 / Flere: 5	1.8kohm	WRM Series	200V	Metal Film	250mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	125°C	-
MMA02040C1201FB300	2693241 Data Sheet RoHS Date/Lot Code	VISHAY Surface Mount MELF Resistor 1.2 kohm MMA Series 200 V Thin Film 250 mW ± 1%	Each (Supplied on Full Reel) Hel rulle Emballagemuligheder	3000+ kr 0,235	Min: 3000 / Flere: 3000	1.2kohm	MMA Series	200V	Thin Film	250mW	± 1%	± 50ppm/K	MiniMELF 0204	-55°C	155°C	AEC-Q200
SMA-A0207BTNT15K	2838155 Data Sheet Date/Lot Code	NEOHM - TE CONNECTIVITY Surface Mount MELF Resistor 15 kohm SMA-A Series 350 V Metal Film 1 W ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 10,000 50+ kr 6,580 250+ kr 5,380 500+ kr 4,280 1000+ kr 3,950 Flere priser...	Min: 5 / Flere: 5	15kohm	SMA-A Series	350V	Metal Film	1W	± 0.1%	± 15ppm/°C	MELF 0207	-55°C	155°C	AEC-Q200
WRM0204HPD-1M0BT3	3782286 Data Sheet RoHS	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 1 Mohm WRM-HP Series 200 V Metal Film 400 mW ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 6,730 50+ kr 5,250 250+ kr 2,990 500+ kr 2,390 1500+ kr 2,090	Min: 5 / Flere: 5	1Mohm	WRM-HP Series	200V	Metal Film	400mW	± 0.1%	± 25ppm/°C	MiniMELF 0204	-55°C	155°C	AEC-Q200
WRM0204HPD-50KBT3	3782288 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 50 kohm WRM-HP Series 200 V Metal Film 400 mW ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 6,220 50+ kr 4,850 250+ kr 2,760 500+ kr 2,200 1500+ kr 1,930 Flere priser...	Min: 5 / Flere: 5	50kohm	WRM-HP Series	200V	Metal Film	400mW	± 0.1%	± 25ppm/°C	MiniMELF 0204	-55°C	155°C	AEC-Q200
WRM0207C-100RF2	2693521 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 100 ohm WRM Series 250 V Metal Film 400 mW ± 1%	Each (Supplied on Full Reel) Hel rulle Emballagemuligheder	2000+ kr 0,326	Min: 2000 / Flere: 2000	100ohm	WRM Series	250V	Metal Film	400mW	± 1%	± 50ppm/°C	MELF 0207	-55°C	125°C	-
WRM0204HPD-5K0BT3	3782287 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 5 kohm WRM-HP Series 200 V Metal Film 400 mW ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 6,220 50+ kr 4,850 250+ kr 2,760 500+ kr 2,200 1500+ kr 1,930 Flere priser...	Min: 5 / Flere: 5	5kohm	WRM-HP Series	200V	Metal Film	400mW	± 0.1%	± 25ppm/°C	MiniMELF 0204	-55°C	155°C	AEC-Q200
MMU01020C1002FB300	1215959RL Data Sheet RoHS Date/Lot Code	VISHAY Surface Mount MELF Resistor 10 kohm MMU Series 100 V Metal Film 200 mW ± 1%	Each (Supplied on Cut Tape) Genoprullet Emballagemuligheder	500+ kr 0,358 1500+ kr 0,304 3000+ kr 0,291	Min: 500 / Flere: 5	10kohm	MMU Series	100V	Metal Film	200mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	125°C	AEC-Q200
SMA-A0102BTNL1K5	2837964 Data Sheet RoHS Date/Lot Code	NEOHM - TE CONNECTIVITY Surface Mount MELF Resistor 1.5 kohm SMA-A Series 200 V Metal Film 300 mW ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 8,880 50+ kr 6,660 250+ kr 4,800 500+ kr 3,830 1500+ kr 3,540 Flere priser...	Min: 5 / Flere: 5	1.5kohm	SMA-A Series	200V	Metal Film	300mW	± 0.1%	± 15ppm/°C	MicroMELF 0102	-55°C	155°C	AEC-Q200
SMA-A0102FTDL1M0	2838008 Data Sheet RoHS Date/Lot Code	NEOHM - TE CONNECTIVITY Surface Mount MELF Resistor 1 Mohm SMA-A Series 200 V Metal Film 300 mW ± 1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 1,240 50+ kr 0,710 250+ kr 0,582 500+ kr 0,528 1500+ kr 0,413 Flere priser...	Min: 5 / Flere: 5	1Mohm	SMA-A Series	200V	Metal Film	300mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	155°C	AEC-Q200
SMA-A0204BTNX15K	2838055 Data Sheet RoHS Date/Lot Code	NEOHM - TE CONNECTIVITY Surface Mount MELF Resistor 15 kohm SMA-A Series 200 V Metal Film 400 mW ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 3,430 50+ kr 3,130 250+ kr 2,470 500+ kr 2,060 1500+ kr 1,900 Flere priser...	Min: 5 / Flere: 5	15kohm	SMA-A Series	200V	Metal Film	400mW	± 0.1%	± 15ppm/°C	MiniMELF 0204	-55°C	155°C	AEC-Q200
SMA-A0207BTNT47K	2838175 Data Sheet RoHS Date/Lot Code	NEOHM - TE CONNECTIVITY Surface Mount MELF Resistor 47 kohm SMA-A Series 350 V Metal Film 1 W ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 7,460 50+ kr 6,400 250+ kr 5,360 500+ kr 4,950 1000+ kr 4,880 Flere priser...	Min: 5 / Flere: 5	47kohm	SMA-A Series	350V	Metal Film	1W	± 0.1%	± 15ppm/°C	MELF 0207	-55°C	155°C	AEC-Q200
SMA-A0207BTNT8K2	2838185 Data Sheet RoHS Date/Lot Code	NEOHM - TE CONNECTIVITY Surface Mount MELF Resistor 8.2 kohm SMA-A Series 350 V Metal Film 1 W ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 10,000 50+ kr 6,580 250+ kr 5,380 500+ kr 4,280 1000+ kr 3,950 Flere priser...	Min: 5 / Flere: 5	8.2kohm	SMA-A Series	350V	Metal Film	1W	± 0.1%	± 15ppm/°C	MELF 0207	-55°C	155°C	AEC-Q200
SMA-A0207BTNT2K2	2838166 Data Sheet RoHS Date/Lot Code	NEOHM - TE CONNECTIVITY Surface Mount MELF Resistor 2.2 kohm SMA-A Series 350 V Metal Film 1 W ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 6,820 50+ kr 5,330 250+ kr 4,450 500+ kr 3,780 1000+ kr 3,600 Flere priser...	Min: 5 / Flere: 5	2.2kohm	SMA-A Series	350V	Metal Film	1W	± 0.1%	± 15ppm/°C	MELF 0207	-55°C	155°C	AEC-Q200
MP000639	3214788 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Surface Mount MELF Resistor 220 ohm 200 V Metal Film 300 mW ± 1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 1,810 50+ kr 1,110 250+ kr 0,579 500+ kr 0,476 1500+ kr 0,341	Min: 5 / Flere: 5	220ohm	-	200V	Metal Film	300mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	155°C	AEC-Q200
WRM0204HPD-10RBT3	3782280 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 10 ohm WRM-HP Series 200 V Metal Film 400 mW ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 6,220 50+ kr 4,850 250+ kr 2,760 500+ kr 2,200 1500+ kr 1,930 Flere priser...	Min: 5 / Flere: 5	10kohm	WRM-HP Series	200V	Metal Film	400mW	± 0.1%	± 25ppm/°C	MiniMELF 0204	-55°C	155°C	AEC-Q200
CMA02040X1000GB300	1713576RL Data Sheet RoHS Date/Lot Code	VISHAY Surface Mount MELF Resistor 100 ohm CMA Series 200 V Carbon Film 400 mW ± 2%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	50+ kr 1,370 250+ kr 1,140 500+ kr 1,080 1500+ kr 0,985 3000+ kr 0,851	Min: 100 / Flere: 5	100ohm	CMA Series	200V	Carbon Film	400mW	± 2%	-250ppm/K	MiniMELF 0204	-55°C	155°C	AEC-Q200
WRM0204C-1K8FI	1505807RL Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 1.8 kohm WRM Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Genoprullet Emballagemuligheder	500+ kr 0,459 1500+ kr 0,308 3000+ kr 0,262	Min: 500 / Flere: 5	1.8kohm	WRM Series	200V	Metal Film	250mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	125°C	-
WRM0204Y-470RBI	1505916 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 470 ohm WRM Series 200 V Metal Film 250 mW ± 0.1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 8,880 50+ kr 6,920 250+ kr 3,950 500+ kr 3,430	Min: 5 / Flere: 5	470ohm	WRM Series	200V	Metal Film	250mW	± 0.1%	± 15ppm/°C	MiniMELF 0204	-55°C	125°C	-
SMA-A0102FTDL12K	2837994 Data Sheet RoHS Date/Lot Code	NEOHM - TE CONNECTIVITY Surface Mount MELF Resistor 12 kohm SMA-A Series 200 V Metal Film 300 mW ± 1%	Each (Supplied on Cut Tape) Klippet bånd Emballagemuligheder	5+ kr 1,480 50+ kr 0,851 250+ kr 0,698 500+ kr 0,582 1500+ kr 0,455 Flere priser...	Min: 5 / Flere: 5	12kohm	SMA-A Series	200V	Metal Film	300mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	155°C	AEC-Q200
MP000654	3214897 Data Sheet RoHS	MULTICOMP PRO Surface Mount MELF Resistor 560 ohm 200 V Metal Film 300 mW ± 1%	Each (Supplied on Full Reel) Hel rulle Emballagemuligheder	3000+ kr 0,342	Min: 3000 / Flere: 3000	560ohm	-	200V	Metal Film	300mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	155°C	AEC-Q200
